PVC Profile Extrusion Machine Customized Cross Section Profile Production

MOQ : 1 SET

Delivery Time : 45 WORKING DAYS

Machine Length : 20m

Model Number : LB-65/28

Extrusion Capacity : 180kg/h

Supply Ability : 15 SETS PER MONTH

Width : 200-600mm

Brand Name : LB

Calibration Table Length : 300MM

Payment Terms : L/C,T/T

Single Screw Extruder : SJ 65/28

Mats Materials : PVC

Price : USD,EUR

Warranty Time : 18 Months

Dimentions : 20*2.5*3m

Certification : CE,ISO

Place of Origin : ZHANGJIAGANG

Frame Wide : 300mm wide

Machinedimensions : Depends on model, e.g., 10m x 1.5m x 2m

Packaging Details : STANDARD PACKAGE

Control : PLC TOUCH SCREEN

Plastic Processed : Polystyrene

Inverter Brand : ABB

Contact Now

PVC Profile Extrusion Machine Customized Cross Section Profile Production
PVC Profile Extrusion Line Overview

PVC is extensively used to produce profiles for windows, technical profiles, and door profiles due to its excellent weathering resistance, impact strength, and durability. PVC provides outstanding insulation for heat and noise while maintaining very low maintenance costs.

LANGBO MACHINERY offers both lead-based and lead-free stabilizers that provide excellent heat and UV resistance to PVC profiles. Our stabilizer system delivers higher mechanical strength, excellent whiteness, and superior color stability. The one-pack system is specially designed with quality additives to ensure smooth extrusion with consistent luster and finish.

PVC Profile Extrusion Machine Customized Cross Section Profile Production
Key Features
  • Conical twin-screw extruder suitable for processing PVC powder raw materials
  • Capability to produce various PVC profiles by changing molds
  • Complete auxiliary machine setup including mixer unit, mold, vacuum calibration table, haul-off machine, cutter, and stacker
PVC Profile Extrusion Machine Customized Cross Section Profile Production PVC Profile Extrusion Machine Customized Cross Section Profile Production PVC Profile Extrusion Machine Customized Cross Section Profile Production PVC Profile Extrusion Machine Customized Cross Section Profile Production
Production Advantages
  • Primarily used for producing PVC window profiles, plastic decorative plates, and PVC foam profiles
  • Frequency conversion for speed regulation
  • Super-taper twin-screw extruder with temperature controlling instrument in screw core
  • 30-40% power savings
  • Rigid gear surface reducer capable of continuous long-term operation
  • Smooth and steady operation with easy mold changing
  • Long usage life
  • Capability to produce steel plastic profiles by changing wood imitation foaming profile molds
PVC Profile Extrusion Machine Customized Cross Section Profile Production
Equipment Configuration
Item Equipment Quantity
1 Screw feeder 1 set
2 SJSZ-65/132 extruder 1 set
3 Vacuum calibration table 1 set
4 Haul off machine 1 set
5 Cutter 1 set
6 Stacker 1 set
7 Mould 1 set
Technical Specifications

The extruder serves as the "heart" of the production line, determining both output capacity and energy consumption. The table below displays screw standards for different production levels.

Model SJZ45 SJZ51 SJZ65 SJZ80 SJZ92
Screw diameter (mm) 45/100 51/105 65/132 80/156 92/188
Screw rotation speed (r/min) 4-45.5 1-30 1-34.7 1-36.9 1-32.9
Effective length of screw (mm) 1000 1050 1430 1800 2520
Main motor power (kW) 15 22 37 55 90
Barrel heating power (kW) 12 18 24 36 48
Capacity (kg/h) 95 110 250 380 520
Central height (mm) 1000
Net Weight (kg) 3000 3200 5000 6500 7500
For customized complete production solutions, please contact us.
